LM386 Audio Amplifier Module
Amplifier module using the LM386 IC with a gain of 200
I bought a few of these a long time ago when I was creating a amplifier to help with managing playback and recording levels on a tape deck used for a ZX Spectrum. I never used the module in that machine but I had bought a selection of modules with the LM386 Ic's on them.
I could not find a schematic for these boards, so I have attempted to reverse engineer it in Kicad.
